Rate Meter
APM
The Advanced Panel Meter (APM) Rate Meter was developed for use in flow applications, production lines and motor speed monitoring. It combines the instant visual representation of an analog meter with the speed and accuracy of a digital meter. The unique display is viewable in most environmental conditions and features a programmable scale and color changing backlight for instant recognition and precision measurement. The APM improves safety and efficiency through user programmable alarm set-points, dynamic backlighting and starburst
messaging that alerts operators of changing conditions instantly. It features digital and analog outputs to communicate with other components in a system, IP65 and NEMA type 4 and 12 ratings and an industry leading three-year warranty.
12-24V AC/DC power supply
User-programmable 40 segment bar graph scale
Alarms to immediately alert operators when a parameter is out of range.
4 character messaging area displays custom messages, alarms and annunciators.
Interface to other equipment using digital and analog outputs.
Output 1: Digital (open collector) or Analog (4-20mA),
Output 2: Digital (open collector) or Analog (4-20mA)
Positive LCD for use in bright conditions.
Accuracy: Up to 0.1%
Certifications: CE, RoHS, UL, NEMA Type 4 and 12
Specifications
| Brand | trumeter |
| Series | APM |
| Model | RATE |
| Form Factor | 72x72mm 9/64 DIN |
| Input Range | 0-60kHz, NPN Transistor Pulses, PNP Transistor Pulses, Push-Pull Pulses |
| Input Frequency | Pulsed, Variable |
| Accuracy | ±0.01% of Full Scale or 50ppm, whichever is greater |
| Output | 4-20mADC, Open Collector |
| Aux. Power Supply | Switching ~12-24VDC |
| Tariff Code | 8531.20.0000 |
| ECCN | EAR99 |
