APPLICATION: With ammeters, wattmeters, and cross current compensation.
FREQUENCY: 50-400 Hz
INSULATION LEVEL: 600V, 10kV BIL full wave
- Terminals are brass studs No 8-32 with one flatwasher, lockwasher, and regular nut.
- Flexible leads are UL 1015, 105°C, CSA approved. #16 AWG, 24" long.
- Non-standard length to be specified.
- SFT case styles also available as SFL with leads.
- Approximate weight: 0.6 lbs
Specifications
| Product | |
|---|---|
| Brand | Instrument Transformers Inc |
| Model | 56 |
| Input Range | 0-250AAC |
| Input Frequency | 60Hz |
| Accuracy | 1% Class |
| Output | 0-5AAC |
| Tariff Code | 8504.31.4035 |
| ECCN | EAR99 |
| Insulation Level | 600V, 10kV BIL full wave |
| Current Transformers | |
|---|---|
| CT Burden VA Max. | 6.0VA |
| CT Ratio | 250:5A |
| CT Window | 2.06" Diameter |
