APPLICATION: Relaying and metering.
FREQUENCY: 50-400 Hz.
INSULATION LEVEL: 600 Volts, 10 kV BIL full wave.
Terminals are brass studs No. 8-32 with one flatwasher, lockwasher and regular nut.
Order mounting bracket kit 0221B00541 separately.
Multi-ratios available upon request.
Specifications
| Product | |
|---|---|
| Brand | Instrument Transformers Inc |
| Model | 24 |
| Input Range | 0-600AAC |
| Input Frequency | 60Hz |
| Accuracy | 0.3 B1.8 |
| Output | 0-5AAC |
| Tariff Code | 8504.31.4035 |
| ECCN | EAR99 |
| Current Transformers | |
|---|---|
| CT Ratio | 600:5A, Multi-Ratio |
| CT Relay Class | C200 |
| CT Window | 2.50" Diameter |
