- Reduces high DC Voltage signals down to 500uADC.
- Accuracy +/-1%
- For use on DC Volts. Each model is 2000 Ohms/Volt.
- For use with Simpson 500uADC meters indicating DC Voltage.
- Can also be used with Simpson digital panel meters in a 0-2mADC range (Must be scaled).
Specifications
| Brand | Simpson Electric |
| Model | 183 |
| Input Range | 0-2500VDC |
| Input Frequency | DC |
| Scale, Range, or Display | 0-2500VDC |
| Tariff Code | 9030.90.8823 |
| ECCN | EAR99 |
