Crompton Instruments
ANSI SWITCHBOARD METERS
High quality range of switchboard instruments which complies with American ANSI-C39.1 (1981) specifications. Available in 4.5 inch case size, the rugged design characteristics meet the needs of the most demanding environmental applications. This extensive range of analog and digital/analog meters can withstand high shock. The range offers various customized options and features UL and CE Listings and Certifications.
Model 007 is a one piece flame retardant polycarbonate moulding with a black matte finished bezel area, and a specially contoured window to minimize reflection from adjacent light sources. Scales are 250° moving coil with parallax error-free platform dials. Standard dials are white matte with black printed scales. The Elapsed Time variant features a synchronous motor running time meter with a non-resettable indicator
As a Crompton Modification center, we reduce the lead times by keeping products on hand. We also offer the ability to create custom artworks for this meter, and the ability to add a logo.
Replaces
- 103-811-AAAB
- 077-156A-PNZH-C6
Specifications
| Brand | Crompton |
| Series | Switchboard |
| Model | 007 |
| Form Factor | 4-Stud Mount, Switchboard: 4.5-Inch ANSI C39.1 |
| Input Range | 110-130VAC |
| Input Frequency | 60Hz |
| Scale, Range, or Display | 0-99,999.99Hrs |
| Tariff Code | 9030.39.9900 |
| ECCN | EAR99 |
