Analog Panel Meters:
Meets or Exceeds ANSI C39.1. 1981
- Repeatability
- Dielectric Test Voltage
- AC Burden
- Self Shielding Instruments
- RoHS Compliant
- Accuracy: 2% of full scale input for AC Iron Vane
Iron Vane Analog Panel Meter Movement Type:
Used primarily in AC Voltage, AC Current and Power Measurement application. Rugged in both design and construction. Advantage of more accurate true RMS measurement capability when distorted or non-sinusoidal waveforms are present.
Iron Vane Analog Panel Meter Movement Type:
Used primarily in AC Voltage, AC Current and Power Measurement application. Rugged in both design and construction. Advantage of more accurate true RMS measurement capability when distorted or non-sinusoidal waveforms are present.
As a Brighton Modification Center, we keep the lead time low by stocking the unfinished meter and performing final modifications. If you would like to use a different artwork, add colored regions, or add a logo, contact us and get it made custom!
Specifications
| Brand | Brighton Electronics |
| Form Factor | 3-Stud Mount, Panel: 2.5-Inch ANSI C39.1 |
| Input Frequency | 60Hz |
| Input Range | 0-150VAC |
| Model | P2 |
| Scale, Range, or Display | 0-15kVAC |
| Tariff Code | 9030.33.3800 |
| ECCN | EAR99 |
